TAPPING MACHINE:
The offered tapping machine is known for its distinctive attribute that is it folds the four sided flaps automatically. This tapping machine is developed using top quality material in compliance with the set norms. We provide this tapping machine from us in customized options as per market preferences.
| Model No. | MMT12/150 | MMT6/85 |
| Tapping Cap,in Solid | ||
| 1.Tapping in Steel | 12mm. | 6mm. |
| 2.Tapping in C.I. | 16mm. | 8mm. |
| 3.Tapping in Allumin | 20mm | 12mm. |
| Spindle Hole | 80mm | 80mm. |
| Tapping in Head | ||
| 1.Spindle Travel(manual) | 75mm. | Fixed |
| 2.Spindle Taper | 1.5 Deg. | JT-2 |
| 3.No.of Spindle speed | 3 | 3 |
| 4.Forward Speeds | 350/620/1100 | 480/1751/1400 |
| 5.Reverse Speeds | 420/745/1315 | 480/750/1400 |
| Electricals | ||
| 1.Power Supply | 415V,3PH. | 415V,3PH. |
| 2.Electrical Motor | 1 H.P.,1440 RPM | 0.5 H.P.,1440 RPM |
| Working Range | ||
| 1.Max.Dist.Between Spindle Centre to Coloum Face | 140mm. | 85mm. |
| 2.Max.Dist.Between Spindle Nose to working Table | 450mm | 175mm. |
| 3.Column Diameter | 75mm | 47mm |
| 4.Tilting Working Table | Fixed | Fixed |
| 5.Vertical Travelers of Arm and With Table(Manual) | 330mm | 180mm. |
| 6.Table With Ram Travels[Up & Down] | --- | 65mm |
| 7.Rotation of Arm &Body[Both Side] | 0-180 Deg. | 0-180 Deg. |
| General | ||
| 1.Working Surface of Base Plate | --- | --- |
| 2.Working Surface of Table(Square) | 220*190 | 145*145 |
| 3.Table Size | 255*381 | 145*145 |
| 4. Base Plate Size | 480*350 | 365*250 |
| 5.No.Of T-Slots &Nominal Size (Base&Table) | ||
| 6.'V'-Belt Section[Inside] | A-71 | --- |
| 7.'V'-Belt Section[Out side] | A-25 | A-37 |
| 8.Overall Size | 321*455*1200 | 365*600*650 |
| 9.Weight of Machine (Approx) | 115kg. | 50kg. |
| Space[LXWXH] | 1400*800*1200. | 400*600*650. |
| Color(s) | MMT GREEN (SPECIAL) | MMT SMOKE GRAY& SILVER GRAY (SPECIAL) |
